普通碟形弹簧

核心提示:普通碟形弹簧Usual disc spring  碟形弹簧具有体积小、储能大、组合合作方便等优良特性,广泛应用于国防、冶金、工程、电力等 普通碟形弹簧Usual disc spring  碟形弹簧具有体积小、储能大、组合合作方便等优良特性,广泛应用于国防、冶金、工程、电力等机械行业。碟形弹簧是承受轴向负荷的碟状弹簧,分为无支承面和有支承面.可以单个使用,也可对合组合或叠合使用、复合组合成

  • 型号:

核心提示:普通碟形弹簧Usual disc spring  碟形弹簧具有体积小、储能大、组合合作方便等优良特性,广泛应用于国防、冶金、工程、电力等 普通碟形弹簧Usual disc spring

  碟形弹簧具有体积小、储能大、组合合作方便等优良特性,广泛应用于国防、冶金、工程、电力等机械行业。碟形弹簧是承受轴向负荷的碟状弹簧,分为无支承面和有支承面.可以单个使用,也可对合组合或叠合使用、复合组合成碟簧组使用。承受静负荷或变负荷。我厂品质遵循GB/T1972-92DIN2093标准,还可为用户设计制造各种非标碟形弹簧。常用材料:60Si2MnA50CrVA和各类不锈钢材料、铬镍铁合金等

图片关键词

参数示意图

系列A D/t≈18;ho/t≈0.4;E=206000 N/mm2;μ=0.3

类别D
(mm)
d
(mm)
t(t')1)
(mm)
ho
(mm)
Ho
(mm)
Ff
(N)
f=0.75ho
(mm)
184.20.40.20.62100.15
105.20.50.250.753290.19
12.56.20.70.316730.23
147.20.80.31.18130.23
168.20.90.351.2510000.26
189.210.41.412500.3
2010.21.10.451.5515300.34
222.511.21.250.51.7519500.38
2512.21.50.552.0529100.41
2814.21.50.652.1528500.49
31.516.31.750.72.4539000.53
35.518.320.82.851900.6
4020.42.250.93.1565400.68
4522.42.513.577200.75
5025.431.14.1120000.83
5628.531.34.3114000.98
63313.51.44.9150001.05
713641.65.6205001.2
804151.76.7337001.28
9046527314001.5
1005162.28.2480001.65
1125762.58.5438001.88
3125648(7.5)2.610.6859001.95
140728(7.5)3.211.2853002.4
1608210(9.4)3.513.51390002.63
1809210(9.4)4141250003
20010212(11.25)4.216.21830003.15
22511212(11.25)5171710003.75
25012714(13.1)5.619.62490004.2

系列B D/t≈28;ho/t≈0.75;E=206000 N/mm2;μ=0.3

类别D
(mm)
d
(mm)
t(t')1)
(mm)
ho
(mm)
Ho
(mm)
Ff
(N)
f=0.75ho
(mm)
184.20.30.250.551190.19
105.20.40.30.72130.23
12.56.20.50.350.852910.26
147.20.50.40.92790.3
168.20.60.451.054120.34
189.20.70.51.25720.38
2010.20.80.551.357450.41
22.511.20.80.651.457100.49
2512.20.90.71.68680.53
2814.210.81.811100.6
231.516.31.250.92.1519200.68
35.518.31.2512.2517000.75
4020.41.51.152.6526200.86
4522.41.751.33.0536600.98
5025.421.43.447601.05
5628.521.63.644401.2
63312.51.754.2571801.31
71362.524.567301.5
804132.35.3105001.73
90463.52.56142001.88
100513.52.86.3131002.1
1125743.27.2178002.4
1256453.58.5300002.63
14072549279003
1608264.510.5411003.38
1809265.111.1375003.83
32001028(7.5)5.613.6764004.2
2251128(7.5)6.514.5708004.88
25012710(9.4)7171190005.25

系列C D/t≈40;ho/t≈1.3;E=206000 N/mm2;μ=0.3

类别D
(mm)
d
(mm)
t(t')1)
(mm)
ho
(mm)
Ho
(mm)
Ff
(N)
f=0.75ho
(mm)
184.20.20.250.45390.19
105.20.250.30.55580.23
12.56.20.350.450.81520.34
147.20.350.450.81230.34
168.20.40.50.91550.38
189.20.450.61.052140.45
2010.20.50.651.152540.49
22.511.20.60.81.44250.6
2512.20.70.91.66010.68
2814.20.811.88010.75
31.516.30.81.051.856870.79
35.518.30.91.152.058310.86
4020.411.32.310200.98
24522.41.251.62.8518901.2
5025.41.251.62.8515501.2
5628.51.51.953.4526201.46
63311.82.354.1542401.76
713622.64.651401.95
80412.252.955.266102.21
90462.53.25.776802.4
100512.73.56.286102.63
1125733.96.9105002.93
125643.54.58154002.38
140723.84.98.7172003.68
160824.35.69.9218004.2
180924.36.211264004.65
2001025.5712.5361005.25
32251126.5(6.2)7.113.6446005.33
2501277(6.7)7.814.8505005.85
