核心提示：符合规范 ISO 10243材质:SAE6150 铬钒钢特性:温度220℃,寿命200万次用途:塑胶模具.冲床模具及一般机械最大压缩比例: 25%产品编号符合规范 ISO 10243材质: SAE6150 铬钒钢 特性: 温度220℃,寿命200万次 用途 :塑胶模具.冲床模具及一般机械最大压缩比例: 25%产品编号孔径A(mm)杆径B(mm)自由长L(mm)常数K(kg/mm)压缩 1
- 型号：
核心提示：符合规范 ISO 10243材质:SAE6150 铬钒钢特性:温度220℃,寿命200万次用途:塑胶模具.冲床模具及一般机械最大压缩比例: 25%产品编号
| 符合规范 ISO 10243 材质: SAE6150 铬钒钢 特性: 温度220℃,寿命200万次 用途 :塑胶模具.冲床模具及一般机械 最大压缩比例: 25% |
| 产品 编号 | 孔径 A (mm) | 杆径 B (mm) | 自由长 L (mm) | 常数 K (kg/mm) | 压缩 15% | 压缩 20% | 压缩 258% | |||
| mm | kg | mm | kg | mm | kg | |||||
| B1025 | 10 | 4.5 | 25 | 2.26 | 3.8 | 8.5 | 5.0 | 11.3 | 6.3 | 14.1 |
| 32 | 32 | 1.79 | 4.8 | 8.6 | 6.4 | 11.5 | 8.0 | 14.3 | ||
| 38 | 38 | 1.74 | 5.7 | 9.9 | 7.6 | 13.2 | 9.5 | 16.5 | ||
| 45 | 44 | 1.53 | 6.6 | 10.1 | 8.8 | 13.5 | 11.0 | 16.8 | ||
| 50 | 51 | 1.31 | 7.7 | 10.0 | 10.2 | 13.4 | 12.8 | 16.7 | ||
| 65 | 64 | 1.09 | 9.6 | 10.5 | 12.8 | 14.0 | 16.0 | 17.4 | ||
| 75 | 76 | 0.77 | 11.4 | 8.8 | 15.2 | 11.7 | 19.0 | 14.6 | ||
| 300 | 305 | 0.21 | 45.8 | 9.6 | 61.0 | 12.8 | 76.3 | 16.0 | ||
| B13x25 | 12.5 | 6.3 | 25 | 4.30 | 3.8 | 16.1 | 5.0 | 21.5 | 6.3 | 26.9 |
| 32 | 32 | 3.39 | 4.8 | 16.3 | 6.4 | 21.7 | 8.0 | 27.1 | ||
| 38 | 38 | 2.99 | 5.7 | 17.0 | 7.6 | 22.7 | 9.5 | 28.4 | ||
| 45 | 44 | 2.51 | 6.6 | 16.6 | 8.8 | 22.1 | 11.0 | 27.6 | ||
| 50 | 51 | 2.00 | 7.7 | 15.3 | 10.2 | 20.4 | 12.8 | 25.5 | ||
| 65 | 64 | 1.53 | 9.6 | 14.7 | 12.8 | 19.6 | 16.0 | 24.5 | ||
| 75 | 76 | 1.35 | 11.4 | 15.4 | 15.2 | 20.5 | 19.0 | 25.7 | ||
| 300 | 305 | 0.29 | 45.8 | 13.3 | 61.0 | 17.7 | 76.3 | 22.1 | ||
| B16x25 | 16 | 8 | 25 | 7.72 | 3.8 | 29.0 | 5.0 | 38.6 | 6.3 | 48.3 |
| 32 | 32 | 5.39 | 4.8 | 25.9 | 6.4 | 34.5 | 8.0 | 43.1 | ||
| 38 | 38 | 4.95 | 5.7 | 28.2 | 7.6 | 37.6 | 9.5 | 47.0 | ||
| 45 | 44 | 4.37 | 6.6 | 28.8 | 8.8 | 38.5 | 11.0 | 48.1 | ||
| 50 | 51 | 3.79 | 7.7 | 29.0 | 10.2 | 38.7 | 12.8 | 48.3 | ||
| 65 | 64 | 3.09 | 9.6 | 29.7 | 12.8 | 39.6 | 16.0 | 49.4 | ||
| 75 | 76 | 2.62 | 11.4 | 29.9 | 15.2 | 39.8 | 19.0 | 49.8 | ||
| 90 | 89 | 2.21 | 13.4 | 29.5 | 17.8 | 39.3 | 22.3 | 49.2 | ||
| 100 | 102 | 1.97 | 15.3 | 30.1 | 20.4 | 40.2 | 25.5 | 50.2 | ||
| 300 | 305 | 0.72 | 45.8 | 32.9 | 61.0 | 43.9 | 76.3 | 54.9 | ||
| B19x25 | 19 | 10 | 25 | 22.04 | 3.8 | 82.7 | 5.0 | 110.2 | 6.3 | 137.8 |
| 32 | 32 | 17.14 | 4.8 | 82.3 | 6.4 | 109.7 | 8.0 | 137.1 | ||
| 38 | 38 | 13.16 | 5.7 | 75.0 | 7.6 | 100.0 | 9.5 | 125.0 | ||
| 45 | 44 | 11.43 | 6.6 | 75.4 | 8.8 | 100.6 | 11.0 | 125.7 | ||
| 50 | 51 | 9.59 | 7.7 | 73.4 | 10.2 | 97.8 | 12.8 | 122.3 | ||
| 65 | 64 | 7.36 | 9.6 | 70.7 | 12.8 | 94.2 | 16.0 | 117.8 | ||
| 75 | 76 | 6.09 | 11.4 | 69.4 | 15.2 | 92.6 | 19.0 | 115.7 | ||
| 90 | 89 | 5.15 | 13.4 | 68.8 | 17.8 | 91.7 | 22.3 | 114.6 | ||
| 100 | 102 | 4.51 | 15.3 | 69.0 | 20.4 | 92.0 | 25.5 | 115.0 | ||
| 115 | 115 | 3.92 | 17.3 | 67.6 | 23.0 | 90.2 | 28.8 | 112.7 | ||
| 125 | 127 | 3.48 | 19.1 | 66.3 | 25.4 | 88.4 | 31.8 | 110.5 | ||
| 150 | 152 | 2.88 | 22.8 | 65.7 | 30.4 | 87.6 | 38.0 | 109.4 | ||
| 300 | 305 | 1.53 | 45.8 | 70.0 | 61.0 | 93.3 | 76.3 | 116.7 | ||
| B26x32 | 26 | 12.5 | 32 | 30.31 | 4.8 | 145.5 | 6.4 | 194.0 | 8.0 | 242.5 |
| 38 | 38 | 22.35 | 5.7 | 127.4 | 7.6 | 169.9 | 9.5 | 212.3 | ||
| 45 | 44 | 19.08 | 6.6 | 125.9 | 8.8 | 167.9 | 11.0 | 209.9 | ||
| 50 | 51 | 15.92 | 7.7 | 121.8 | 10.2 | 162.4 | 12.8 | 203.0 | ||
| 65 | 64 | 12.55 | 9.6 | 120.5 | 12.8 | 160.6 | 16.0 | 200.8 | ||
| 75 | 76 | 10.10 | 11.4 | 115.1 | 15.2 | 153.5 | 19.0 | 191.9 | ||
| 90 | 89 | 8.57 | 13.4 | 114.4 | 17.8 | 152.5 | 22.3 | 190.7 | ||
| 100 | 102 | 7.45 | 15.3 | 114.0 | 20.4 | 152.0 | 25.5 | 190.0 | ||
| 115 | 115 | 6.63 | 17.3 | 114.4 | 23.0 | 152.5 | 28.8 | 190.6 | ||
| 125 | 127 | 5.89 | 19.1 | 112.2 | 25.4 | 149.6 | 31.8 | 187.0 | ||
| 150 | 152 | 4.88 | 22.8 | 111.3 | 30.4 | 148.4 | 38.0 | 185.4 | ||
| 175 | 178 | 4.18 | 26.7 | 111.6 | 35.6 | 148.8 | 44.5 | 186.0 | ||
| 200 | 203 | 3.65 | 30.5 | 111.1 | 40.6 | 148.2 | 50.8 | 185.2 | ||
| 300 | 305 | 2.34 | 45.8 | 107.1 | 61.0 | 142.7 | 76.3 | 178.4 | ||
| B32x38 | 32 | 16 | 38 | 39.59 | 5.7 | 225.7 | 7.6 | 300.9 | 9.5 | 376.1 |
| 45 | 44 | 33.06 | 6.6 | 218.2 | 8.8 | 290.9 | 11.0 | 363.7 | ||
| 50 | 51 | 27.76 | 7.7 | 212.4 | 10.2 | 283.2 | 12.8 | 353.9 | ||
| 65 | 64 | 21.63 | 9.6 | 207.6 | 12.8 | 276.9 | 16.0 | 346.1 | ||
| 75 | 76 | 17.55 | 11.4 | 200.1 | 15.2 | 266.8 | 19.0 | 333.5 | ||
| 90 | 89 | 14.39 | 13.4 | 192.1 | 17.8 | 256.1 | 22.3 | 320.2 | ||
| 100 | 102 | 12.45 | 15.3 | 190.5 | 20.4 | 254.0 | 25.5 | 317.5 | ||
| 115 | 115 | 10.92 | 17.3 | 188.4 | 23.0 | 251.2 | 28.8 | 314.0 | ||
| 125 | 127 | 9.49 | 19.1 | 180.8 | 25.4 | 241.0 | 31.8 | 301.3 | ||
| 150 | 152 | 7.96 | 22.8 | 181.5 | 30.4 | 242.0 | 38.0 | 302.5 | ||
| 175 | 178 | 6.86 | 26.7 | 183.2 | 35.6 | 244.2 | 44.5 | 305.3 | ||
| 200 | 203 | 6.03 | 30.5 | 183.6 | 40.6 | 244.8 | 50.8 | 306.0 | ||
| 250 | 254 | 4.73 | 38.1 | 180.2 | 50.8 | 240.3 | 63.5 | 300.4 | ||
| 300 | 305 | 3.88 | 45.8 | 177.5 | 61.0 | 236.7 | 76.3 | 295.9 | ||
| B38x50 | 38 | 20 | 51 | 35.40 | 7.7 | 270.8 | 10.2 | 361.1 | 12.8 | 451.4 |
| 65 | 64 | 27.00 | 9.6 | 259.2 | 12.8 | 345.6 | 16.0 | 432.0 | ||
| 75 | 76 | 27.45 | 11.4 | 312.9 | 15.2 | 417.2 | 19.0 | 521.6 | ||
| 90 | 89 | 19.39 | 13.4 | 258.9 | 17.8 | 345.1 | 22.3 | 431.4 | ||
| 100 | 102 | 16.63 | 15.3 | 254.4 | 20.4 | 339.3 | 25.5 | 424.1 | ||
| 115 | 115 | 14.49 | 17.3 | 250.0 | 23.0 | 333.3 | 28.8 | 416.6 | ||
| 125 | 127 | 13.06 | 19.1 | 248.8 | 25.4 | 331.7 | 31.8 | 414.7 | ||
| 150 | 152 | 10.71 | 22.8 | 244.2 | 30.4 | 325.6 | 38.0 | 407.0 | ||
| 175 | 178 | 9.08 | 26.7 | 242.4 | 35.6 | 323.2 | 44.5 | 404.1 | ||
| 200 | 203 | 7.86 | 30.5 | 239.3 | 40.6 | 319.1 | 50.8 | 398.9 | ||
| 250 | 254 | 6.22 | 38.1 | 237.0 | 50.8 | 316.0 | 63.5 | 395.0 | ||
| 300 | 305 | 5.20 | 45.8 | 237.9 | 61.0 | 317.2 | 76.3 | 396.5 | ||
| B51x65 | 51 | 25 | 64 | 42.14 | 9.6 | 404.5 | 12.8 | 539.4 | 16.0 | 674.2 |
| 75 | 76 | 34.59 | 11.4 | 394.3 | 15.2 | 525.8 | 19.0 | 657.2 | ||
| 90 | 89 | 29.39 | 13.4 | 392.4 | 17.8 | 523.1 | 22.3 | 653.9 | ||
| 100 | 102 | 25.00 | 15.3 | 382.5 | 20.4 | 510.0 | 25.5 | 637.5 | ||
| 115 | 115 | 21.94 | 17.3 | 378.5 | 23.0 | 504.6 | 28.8 | 630.8 | ||
| 125 | 127 | 19.59 | 19.1 | 373.2 | 25.4 | 497.6 | 31.8 | 622.0 | ||
| 150 | 152 | 15.71 | 22.8 | 358.2 | 30.4 | 477.6 | 38.0 | 597.0 | ||
| 175 | 178 | 13.67 | 26.7 | 365.0 | 35.6 | 486.7 | 44.5 | 608.3 | ||
| 200 | 203 | 11.94 | 30.5 | 363.6 | 40.6 | 484.8 | 50.8 | 606.0 | ||
| 250 | 254 | 9.08 | 38.1 | 345.9 | 50.8 | 461.3 | 63.5 | 576.6 | ||
| 300 | 305 | 7.45 | 45.8 | 340.8 | 61.0 | 454.5 | 76.3 | 568.1 | ||
